Deskripsi
– Weight
25.4 kg (excl. battery)
32 kg (incl. battery)
32 kg (incl. battery)
– Max Takeoff Weight[1]
Max takeoff weight for spraying: 52 kg (at sea level)
Max takeoff weight for spreading: 58 kg (at sea level)
Max takeoff weight for spreading: 58 kg (at sea level)
– Max Diagonal Wheelbase
1925 mm
– Dimensions
2585ร2675ร780 mm (arms and propellers unfolded)
1475ร1540ร780 mm (arms unfolded and propellers folded)
1050ร690ร820 mm (arms and propellers folded)
1475ร1540ร780 mm (arms unfolded and propellers folded)
1050ร690ร820 mm (arms and propellers folded)
– Hovering Accuracy Range (with strong GNSS signal)
D-RTK enabled:
Horizontal: ยฑ10 cm, Vertical: ยฑ10 cm
D-RTK disabled:
Horizontal: ยฑ60 cm, Vertical: ยฑ30 cm (radar module enabled: ยฑ10 cm)
Horizontal: ยฑ10 cm, Vertical: ยฑ10 cm
D-RTK disabled:
Horizontal: ยฑ60 cm, Vertical: ยฑ30 cm (radar module enabled: ยฑ10 cm)
– RTK/GNSSOperating Frequency
RTK:
GPS L1/L2, GLONASS F1/F2, BeiDou B1I/B2I/B3I, Galieo E1/E5b, QZSS L1/L2
GNSS:
GPS L1, BeiDou B1I, GLONASS F1, Galieo E1, QZSS L1
GPS L1/L2, GLONASS F1/F2, BeiDou B1I/B2I/B3I, Galieo E1/E5b, QZSS L1/L2
GNSS:
GPS L1, BeiDou B1I, GLONASS F1, Galieo E1, QZSS L1
– Max Configurable Flight Radius
2000 m
– Max Wind Resistance
6 m/s
