Deskripsi
Specifications:
- Secondary Development Supported –
- 31 Degrees of Freedom (Joint Freedom๏ผ –
- 6 Single Leg Degrees of Freedom –
- 7 Single Arm Degrees of Freedom –
- 3 Waist Degrees of Freedom –
- 2 Head Degrees of Freedom –
- Support Bionic Head with Facial Features –
- Industrial grade crossed roller bearings (high precision, high load capacity) –
- Low inertia high-speed internal rotor PMSM (better response speed and heat dissipation) –
- 120N.M Maximum Torque of Arm Joint –
- 360N.M Maximum Torque of Leg Joint –
- Peak: ~15 kg; Rated: ~7 kg Arm Maximum Payload –
- 1045mm Calf + Thigh Length and 690mm Forearm + Upper Arm Length –
- Aircraft-Grade Aluminum + Titanium Alloy + High-Strength Engineering Plastics –
- Local air cooling system –
- Basic Computing Power PCI: Intel Core i5 (Platform Capabilities) –
- Humanoid Binocular Camera with Wide Field of View Sensing Sensor –
- Array Microphone and High-Power Speaker for Voice Interaction –
- Supported Higher-Power Computing Module (inside the body) up to Jetson AGX Thor (2070 TOPS) (One H2 robot maximum equipped two computing module inside the H2 Robot Body)
