Deskripsi
In The Box
- Remote Controller ร1
- Specifications
- OcuSync
- Operating Frequency Range* : 5.150-5.250 GHz; 5.725-5.850 GHz
- Transmitter Power (EIRP)
- 2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
- 5.1 GHz: <23 dBm (FCC/CE)
- 5.8 GHz: <33 dBm (FCC), <14 dBm (CE), <30 dBm (SRRC)
Wi-Fi
- 802.11 a/b/g/n/ac/ax
- Operating Frequency Range*: 2.4000-2.4835 GHz; 5.150-5.250 GHz; 5.725-5.850 GHz
- Transmitter Power (EIRP)
- 2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC)
- 5.1 GHz: <26 dBm (FCC), <23 dBm (CE/SRRC/MIC)
- 5.8 GHz ๏ผ26 dBm (FCC/SRRC), ๏ผ14 dBm (CE)
Bluetooth
- Bluetooth 5.2
- Working frequency: 2.4000-2.4835 GHz
- Transmitter Power (EIRP): <10 dBm
General
- Model: TKPL2
- Battery Type: Li-ion (6500 mAh @ 7.2 V)
- Chemical System: LiNiCoAlO2
- It is recommended to use USB-C chargers with maximum rated power of 100W
- Rated Power: 12.5 W
- GNSS: GPS + Galileo + BeiDou
- Video Output Port: HDMI Type-A
- Operating Temperature: -4ยฐ to 122ยฐ F (-20ยฐ to 50ยฐ C)
- Storage Temperature
- Within one month: -22ยฐ to 113ยฐ F (-30ยฐ to 45ยฐ C)
- One to three months: -22ยฐ to 95ยฐ F (-30ยฐ to 35ยฐ C)
- Three months to one year: -22ยฐ to 86ยฐ F (-30ยฐ to 30ยฐ C)
- Charging Temperature: 41ยฐ to 104ยฐ F (5ยฐ to 40ยฐ C)
- * Operating frequency allowed varies among countries and regions. Please refer to local laws and regulations for more information.
Compatibility
- DJI Matrice 4 Series
